RTX1 Bluetooth UHF Scanner
RTX1 is a handheld Bluetooth reader/writer that integrates tag reading/writing and data transmission into a single device. It flexibly adapts to various Android smartphones, tablets and other smart devices, enabling customers to retrieve tag information in real time. It is widely applicable in library management, warehouse management, the power industry, asset management, and inspection/patrol operations.
Key Features:
- Features the latest Impinj R2000 UHF solution for extended read range and high recognition rates
- 6000mAh high-capacity battery delivers exceptional endurance
- Supports dual scanning modes: UHF RFID and 1D/2D barcode reading
- Adjustable output power
- Offline storage capacity for 7000 tags and barcode records
- Supports Bluetooth 4.0 and USB data transfer
- Compatible with mobile devices running Android, iOS and other platforms
- 0.9-inch OLED display provides intuitive status indicators
Basic Parameters:
Physical Parameters
- RFID Operating Frequency 860-960 MHz
- RFID Communication Standard ISO 18000-6C (C1G2)
- RFID Core Chip Impinj R2000
- RFID Antenna 5dBi antenna
- Display 0.9-inch OLED display
- Operating Current <2A
- Audible Alert Buzzer
- Memory 2MB flash, capable of storing no fewer than 7000 data entries
- Buttons Power button, power setting ‘+’/‘-’, reset button, module switch button, scan button
- Interface Micro USB 2.0
- Bluetooth Bluetooth 4.0 protocol standard
- Battery 3.7V, 6000mAh lithium battery, rechargeable
- Dimensions 251*100*32mm
- Weight 460g
- Colour Options Gloss Black/Opal White
Data Acquisition and Output
- One-dimensional barcodes
Supports Code39, ITF25, Code25, Code11, Code128, Code93, ISBN, Codabar, UPC-A, UPC-E, EAN-13, EAN-8 - Two-dimensional barcodes
PDF417, QR Code, Data Matrix, Code49, Code16K, MaxiCode, CodeOne, OCR-B, Chinese-sensible code
Operating Environment
- Operating temperature -20°C to 55°C
- Storage temperature -20°C to 85°C
- Humidity 5%RH to 95%RH (non-condensing)
- Cooling method Natural air cooling
